Exercise 6.8 — Resilience Probe: Web + API + Redis

Exercises are guided practice for the lecture material. They are non-graded, but later graded assignments assume this work has been completed.

System Diagram​

Web API Redis system diagram

Starter Code Download​

Why you are doing this (and why it matters later)​

Lecture 08 introduces the core reliability distinction between process startup and service readiness. In real systems, dependencies restart and transient failures happen. This exercise practices designing /healthz and /readyz, observing Compose health states, and injecting failures so students can prove the system degrades gracefully and recovers without manual intervention.

This exercise makes us practice:

  • use health and readiness endpoints for machine-readable service state
  • interpret Docker Compose health transitions during boot and failures
  • simulate dependency disruption and validate retry/backoff behavior
  • collect evidence from logs and probes to locate the failing service

Starting Instructions​

  1. Download the Exercise 6.8 starter code archive from the course site and extract it.
  2. Open a terminal in the extracted folder that contains compose.yml.
  3. Run docker compose up -d --build to build and start web, api, and redis.
  4. Run docker compose ps and confirm all services are up before starting probes.
  5. Keep a second terminal ready for logs with docker compose logs -f web api redis.

Exercise Instructions​

Part A (10-15 min): Baseline Health and Readiness​

  1. Probe api with curl http://localhost:3000/healthz and curl http://localhost:3000/readyz.
  2. Probe web with curl http://localhost:3001 and record the response when the stack is healthy.
  3. Capture one docker compose ps snapshot and identify health states (starting, healthy, or unhealthy).

Part B (15-20 min): Inject and Observe Failure​

  1. Inject disruption using docker compose restart redis.
  2. While Redis restarts, repeatedly run curl http://localhost:3001 and curl http://localhost:3000/readyz.
  3. Follow logs with docker compose logs -f web api redis and note exactly when symptoms begin and recovery occurs.
  4. Describe whether failures are brief degradation (503) or persistent crash behavior.

Part C (15-20 min): Tune Recovery Behavior​

  1. In web/server.js, change retry parameters in withRetry usage to attempts = 6 and baseMs = 200.
  2. Rebuild only web using docker compose up -d --build web.
  3. Repeat the Redis restart experiment and compare user-visible failures before vs after tuning.
  4. Write a short evidence-based conclusion about whether increased retry/backoff improved resilience.

AI Assist Ideas (Optional)​

AI use is allowed for this exercise. Prompt log requirement: AI assistance is allowed, but you must log every prompt/response in prompt-log.md with tool name, exact prompt, and a short note describing how you used the result.

Suggested prompts (adapt to your exact code context):

  1. Explain the withRetry function and predict total worst-case wait time for 6 attempts with 200ms base delay.
  2. Given the readyz handler in the API service, what false-positive readiness risks still exist?
  3. I observed intermittent 503 responses after restarting Redis with Docker Compose. Suggest a debugging checklist focused on logs and probe sequencing.

Target behavior:

  • /healthz remains 200 while service processes are alive
  • /readyz reflects dependency state and can return 503 during Redis outages
  • web may briefly degrade during Redis disruption but should recover without manual restarts
  • students can identify the offending dependency from probe outputs plus logs

Saving Your Work​

  1. Save only the files you changed for this exercise in your extracted exercise folder.
  2. Keep notes and timeline evidence in exercise-notes.md (or an equivalent text file).
  3. Keep at least one screenshot of docker compose ps and your before/after retry comparison for class discussion.

Verifying Your Work​

  1. Run docker compose ps and confirm healthy state after experiments complete.
  2. Re-run curl checks for http://localhost:3000/healthz, http://localhost:3000/readyz, and http://localhost:3001.
  3. Demonstrate that the stack recovers after docker compose restart redis.
  4. Ensure your before/after comparison of retry settings is based on observed outputs, not assumptions.

Solution Walkthrough​

  1. Compare your probe order against the lecture's observability sequence: compose ps -> logs -> endpoint probes -> in-container checks.
  2. Review web/server.js and api/server.js from your downloaded exercise code to explain why behavior changed.
  3. Use your timeline to justify which service was the initial source of failure and why.
